Designed for H₂ Infrastructure

Volz VH₂ fittings deliver robust performance across the entire hydrogen value chain:

• Refueling Stations
  Secure connections and leak-tight operation under dynamic pressure peaks.
• Transport & Storage
  Hydrogen trailers and pressure vessels remain sealed with proven, high-integrity fittings.
• Electrolyzers & Compressors
  Reliable integration under fluctuating pressures and temperatures.
• Fuel Cell Systems
  Supporting system longevity and operational safety through precise, durable connections.

​Technical Highlights

• Material: 1.4571 / AISI 316Ti stainless steel (DIN EN 10088‑3)
• Tube Sizes: 6 – 16 mm
• Connection Standards: DIN 2353 / ISO 8434‑1, ISO 1179‑4 (Form B), ISO 3852 (Form C), ASME/ANSI B1.20.1
• Temperature Range: –40 °C to +85 °C
• Pressure & Leak Testing: TÜV SÜD (ISO DIS 19887:2023) – 700 bar test (sf 1.25), DNV (TAP00000HU) – up to 800 bar (sf 4), tested with hydrogen gas/emulsion​​

Why Volz?

• Over 60 years of cutting-ring expertise
• Fully vertically integrated manufacturing – Made in Germany
• High traceability & documentation, including batch certificates and 3.1 material traceability
• Component-level certifications from TÜV SÜD, DNV, Lloyd’s, DVGW, ABS and more

Partner with Volz to secure efficient, future-ready hydrogen infrastructure — from production to mobility.
