Lightweight aluminum High-flow valve:
- CV: 0.86
- Fast-filling: full flow at ultra low tank pressure
High-flow excess flow valve:
- No impact on filling flow
- Easily calibrated
- Auto reset
High-flow TPRD: vented, glass bulb T=110±10°C
Pressure sensor port option: SAE/ORB
Low-torque/high-flow bleed valve:
- Drive vehicle or drain tank
- Life > 100 cycles
Live port for remote PRD:
- For optional remote PRD or sensor
- IFS format (ø 6 mm or ø 8 mm)
Temperature sensor
Total Mass: 10,72g
Certifications:
ECE R134
